450 Degree High-Temperature Resistant Flexible Duct

Geli 450 Degree High-Temperature Resistant Flexible Duct is the latest invention of high-quality and with 1-year warranty. It is widely used in metallurgy, electricity, chemical industry, aerospace and other fields, for conveying high-temperature smoke, gas and steam, to ensure the and safety of the production process.

Parameter (Specification)

Feature And Application

Structure of 450 Degree High-Temperature Resistant Flexible Duct : Patent CP structure, special glass fiber coating, external spiral, galvanized steel clip plate (steel plate inlaid with wear-resistant plastic.

Performance of 450 Degree High-Temperature Resistant Flexible Duct: Good vacuum characteristics, the external spiral galvanized plate plays a good role in wear resistance, and will not damage the air duct when dragged on the ground,, flexible telescopic, and can also be flame retardant, insulating, heat resistant, vibration resistant, strong toughness, and resistant to chemical corrosion.

Colorof 450 Degree High-Temperature Resistant Flexible Duct : gray/inner white/galvanized steel plate;

Application scope of 450 Degree High-Temperature Resistant Flexible Duct: Used for diesel engine test bench, automobile exhaust emission, high-temperature boiler suction, exhaust equipment, structure, heating engine, dust, powder, fiber and other solids, dust removal suction device, heater exhaust, compressor, etc., low-pressure environment, such as engineering, coal mines, etc.

Temperature range: about -30°C to 400°C, short time can reach 450.

Details

Temperature resistanceof 450 Degree High-Temperature Resistant Flexible Duct : It can operate normally within the temperature range of -60℃ to  400℃. After 12 hours of high temperature at 400 degrees, the product shows no damage.

Elasticity of 450 Degree High-Temperature Resistant Flexible Duct: It can withstand 10000 stretching and contraction cycles without rupture, has good elastic performance.
